New Energy Wind & Photovoltaic Step-up Distribution Box Type Transformer Substation
ZTELEC Electric Technology (Zhengzhou) Co., Ltd
As the global energy transition accelerates, integrating wind and photovoltaic (PV) power into smart grid systems requires advanced substation solutions that ensure reliability and efficiency. ZTELEC Electric Technology presents its cutting-edge Step-up Distribution Box Type Transformer Substation, designed to optimize renewable energy transmission while minimizing carbon footprint.
Energy Storage Step-up Substation integrated with Converter
Product Overview & Technical Advantages
Our substation combines modular design with high-performance components, tailored for distributed wind and PV projects:
-
Modular Scalability
- Compact box-type structure reduces on-site installation time by 40% compared to traditional substations .
- Supports incremental capacity expansion from 0.66kV to 35kV voltage levels.
-
Energy Efficiency
- Integrated smart monitoring system (SCADA-compatible) ensures real-time fault detection and load balancing.
- Lossless transformer technology achieves 99.2% energy conversion efficiency .
-
Environmental Adaptability
- IP54-rated enclosure withstands extreme weather conditions (-40°C to +50°C operating range).
- Corrosion-resistant materials meet IEC 60068 standards for coastal and high-salinity environments.
-
Outdoor Box-type Substation
Common Model Specifications
| Model Series | Voltage Rating | Capacity Range | Dimensions (L×W×H) | Application Field |
|---|---|---|---|---|
| ZT-SUB-1000 | 10kV/0.4kV | 630-2000kVA | 3.2m×1.5m×2.0m | Small wind farms, rooftop PV systems |
| ZT-SUB-3000 | 35kV/10kV | 2500-5000kVA | 5.0m×2.5m×3.0m | Utility-scale wind parks, hybrid renewable projects |
| ZT-SUB-HV | 110kV/35kV | 8000-12000kVA | 8.0m×3.5m×4.5m | Grid interconnection hubs, offshore wind farms |
Sri Lanka 2MW photovoltaic farm project purchases 2500kVA photovoltaic box transformer
Why Choose ZTELEC?
- Proven Track Record: Over 200 installations in China’s wind-rich regions (e.g., Chile， Mongolia， Russia， Lebanon) and solar parks .
- Customization: Tailored solutions for hybrid systems combining wind, PV, and energy storage
- Certifications: ISO 9001, CE, and TUV Rheinland approvals for global markets.
Call to Action
Accelerate Your Renewable Energy Project with ZTELEC!
- Request a Free Technical Consultation: Our engineers will assist in selecting the optimal model based on your project’s power demand and grid requirements.
- Bulk Order Incentives: Quantity discounts available for orders exceeding 5 units.
- Fast Delivery: Standard models ship within 15 working days post-order confirmation.
Contact Us Today!
📞 WhatsApp/WeChat: +86-157 1674 9170
📧 Inquiry: [email protected]
🌐 Website: https://www.hnztelec.com
Industry Trends Supporting Our Solution
- Global wind energy capacity is projected to grow by 6% annually through 2030, driven by policies like China’s “Dual Carbon” targets
- Hybrid wind-PV systems reduce curtailment risks by 30-50% through complementary power generation patterns
ZTELEC Electric Technology is committed to empowering the energy transition with innovative, future-proof infrastructure. Let us help you harness the full potential of new energy resources!
。
