1000 kVA Dry‑Type Step‑up Transformer for PV Solar Station
10-28 2025 | By:
The 1000 kVA dry-type step-up transformer is commonly used in medium-scale PV solar stations. With high efficiency, low noise, and excellent reliability, ZTelec Yuguang provides transformers engineered for PV inverter outputs to grid integration.
Specifications Table
| Parameter | Value |
|---|---|
| Rated Capacity | 1000 kVA |
| Primary Voltage | 0.69 kV / 1 kV |
| Secondary Voltage | 10 kV / 20 kV |
| Cooling Method | Air Natural (AN) |
| Insulation Class | F class resin |
| Impedance | 4–6 % |
| Noise Level | ≤ 62 dB |
| Mounting Type | Indoor / Semi‑outdoor |
PV Applications
-
Suitable for PV power stations ranging from 1 MW to 5 MW.
-
Stepping up inverter output to grid voltage.
-
Compact footprint suitable for indoor inverter rooms or semi-outdoor transformer stations.
13.2/0.48kV 2000kVA Dry type transformer Chile project
Procurement Guidance
-
Verify rated capacity matches solar inverter design.
-
Check transformer insulation and cooling method for ambient conditions.
-
Consider branded auxiliary equipment options (ABB/Schneider).
-
Ensure local grid compliance and low-loss requirements
ZTelec Manufacturer Advantage
-
Experienced PV transformer manufacturer with OEM capabilities.
-
Custom voltage, taps, and accessories available.
-
Worldwide export and after-sales support ensures reliable PV deployment.
