What is a Phase-shifting Rectifier Transformer?

A phase-shifting rectifier transformer is a specially designed transformer used in inverter systems
to reduce harmonic distortion, improve power factor, and enhance the efficiency of rectification.
By introducing phase-shifted secondary windings, it enables multi-pulse rectification (such as 12-pulse, 24-pulse, or 36-pulse systems)
to meet the needs of modern power electronics applications.

Models and Specifications

• Rated Capacity: 100 kVA – 12000 kVA (customizable)
• Primary Voltage: 6 kV / 10 kV / 20 kV /35kV (or as required)
• Secondary Voltage: 380 V / 690 V / 1140 V
• Phase-shift Angles: 15°, 30°, 45° depending on rectification requirements
• Pulses: 6-pulse / 12-pulse / 24-pulse / 36-pulse
• Cooling Method: ONAN / ONAF
• Insulation Class: F / H class

Application Scenarios

Phase-shifting rectifier transformers from ZTELEC YUGUANG are widely applied in:

• Inverter systems for renewable energy (solar PV, wind power)
• Medium-voltage drives for motors and pumps
• Metallurgy and mining rectifier systems
• Industrial electrolysis and plating plants
• Railway traction and DC transmission projects

Advantages of ZTELEC YUGUANG Rectifier Transformers

• Custom Design: Flexible configuration for voltage, capacity, and phase-shifting angle.
• High Efficiency: Optimized winding design ensures reduced losses and improved power factor.
• Low Harmonics: Supports 12-pulse/24-pulse rectification, reducing harmonic distortion in power grids.
• Durability: Robust insulation materials guarantee long service life under harsh conditions.
• Trusted Manufacturer: With decades of experience, ZTELEC YUGUANG delivers reliable products to global customers.

Why Choose ZTELEC YUGUANG?

ZTELEC YUGUANG is a specialized manufacturer of phase-shifting rectifier transformers for inverter systems.
We provide tailored solutions that meet international standards, offering products with excellent performance and competitive pricing.
Our transformers are widely exported to Europe, Asia, Africa, and North America, earning strong trust from industrial customers.

Contact Us for a Quote

Looking for a reliable phase-shifting rectifier transformer supplier?
ZTELEC YUGUANG is your ideal partner.
Contact us today for technical consultation and the best pricing.
