110kV/132kv oil-immersed Power Transformer

Overview

In response to the global growth in electricity demand, 110kV /132kv three-phase oil-immersed transformers are widely used in national power grids, industrial and mining enterprises, regional substations, power plant step-up stations, and public utility systems.
These transformers are mainly designed for voltage step-up or step-down applications, ensuring efficient energy transmission and reliable power distribution.

With a maximum capacity of up to 200 MVA, our 110kV/132kv  transformers have been proven in high-reliability operation across more than 50 countries and regions, including Tanzania, Zimbabwe, Ghana, South Africa, Kenya, Zambia, Sudan, Libya, Congo, the UAE, Saudi Arabia, Iraq, Syria, and Bangladesh.

110kV /132kv Power Transformer Advantages

1. Standards Compliance
   Designed and manufactured according to GB, IEC, GOST, EN, NF, ANSI/IEEE standards (customizable per client requirements).

2. Certifications
   Certified by ISO, CE, IEC, SABS, COC, CSA, and UL to ensure international quality and safety compliance.

3. High Efficiency
   The efficiency of the 110kV transformer exceeds 99%, meeting the EU Eco-design Tier 2 (2015/2014/548/EC) energy efficiency requirements.

4. Proven Performance
   With extensive project experience in global grid modernization and renewable energy integration (e.g., photovoltaic step-up stations), our products demonstrate exceptional stability under complex conditions with a service life exceeding 30 years.

5. Eco-Friendly and Sustainable Design
   Uses FR3 natural ester insulation oil and recyclable materials to minimize carbon footprint, fully aligned with green energy and carbon neutrality policies.

6. Fast Delivery Capability
   Standard delivery time: 90 days
   Shortest possible lead time: 50 days

110kV /132kv Power Transformers Types

At ZTelec Electric, we manufacture a full range of 110kV power transformers, including three-phase double-winding, three-phase triple-winding, and autotransformers.
While they operate on the same principle, their structural differences suit various applications. ZTelec provides tailor-made transformer solutions for your specific power system needs.

• 110kV/132kv  Three-Phase Double-Winding Transformer
  Used for standard voltage transformation between primary and secondary systems.

• 110kV/132kv  Three-Phase Triple-Winding Transformer
  Designed for applications requiring dual secondary voltage levels, such as combined grid and industrial power supply.

• 110kV /132kv Autotransformer
  Offers compact size and high efficiency, ideal for interconnection between high-voltage networks.

110kV /132kv Power Transformer Technical Parameters
